项目名称 | 规格型号 | 数量 π | 材质 | ||
1.1 | 本体2.0MM碳钢底座及壳体Body 2.0MM carbon steel base and housing | 底座≥5mm 呆护罩≥2mm Base ≥5mm Protective cover ≥2mm | 套 |
1 | 2.0MM碳钢 2.0MM carbon stee |
1.2 | 自吸粉碎泵(含配套虹吸箱)Self-priming crushing pump (including matching siphon box) | 功率2.2KW,8M扬程,5米吸深 Power 2.2KW,8M head,5m suction depth | 台 set | 1 | |
1.3 | 控制阀门 Control valve | 套 set | 4 | 铜芯 Copper core | |
1.4 | 电气控制箱及装置控制系统Electrical contro box and device control system | 套 | 1 | ||
1.5 | 收集软管(含管道元件)Collect hose(with pipe elements) | 管径32 mm Pipe diameter 32 mm | 米 meter |
10 | PVC钢丝 增强软管 PVC wire Reinforcement hose |
1.6 | 软管 含管道 piping elements) | 管径32 mm Pipe diameter 32 mm | 米 meter |
10 | PVC钢丝 增强软管 PVC wire Reinforcement hos |
1.7 | 生活污水标准排放法兰及短接Domestic sewage standard discharge flange and short COnnection | GB3657-2011《油污水和生活污水国ji通 岸接头》 GB3657-2011"Oil sewage and domestic sewage International shore connection" | 片 piece |
1 | 碳钢 Carbon steel |
1.8 | 手动卷管挂架 Manual coil hanger | 套 | 2 | ||
1.9 | K箱 Water Tank | 盘 | 1 |
